Frimaq Model VCC-Plus BC Vacuum Packaging Machine

The Frimaq Model VCC-Plus BC Vacuum Packaging Machine utilizes an automatic process which, takes a bag with product, vacuums it and seals it hermetically.

The Frimaq Model VCC-Plus BC Vacuum Packaging Machine Meats CE Standards.

RAM Manufacturing Equipment located in Corona, California, offers training, installation, service and parts for all the machines we sell. Including the Frimaq Model VCC-Plus BC Vacuum Packaging Machine and many others. Call or visit us today for more information!

Features

• Machine capability is from 0 to 3.5 cycles/ minute depending on the vacuum pumps capability, product temperature, etc.
• Conveyor belt is adapted for 1 or 2 operators.
• Machine is adapted to work on both sides; left and right.
• The machine is manufactured with materials suitable for food contact.
• Conveyor belt is smooth without joints.
• Conveyor belt has a coating to avoid leaks on both sides and lateral edges.
• Loading bars have a non-stick coating for fitted bags.
• Safety guards for operators are set at the inlet and outlet area.
• Safety guards for hands are set at the loading area.
• Intuitive self-adjustable touch screen is set with 10 programs to be adapted to different products.
• Control Panel is located near the operator (centred for two operators).
• Emergency stop with quick system switch-off.
• Standby mode adjustable by seconds.
• Alarms on screen.
• Pump start-up from screen.
• Maintenance menu.
• 75 different step speed, with modifiable ramps.
• Hood manual-pneumatic-mechanical locking at top position to assure repairs safety.
• Manual working mode (for vacuum cycles).
• Semi-automatic working mode (for step plus vacuum cycle).
• Automatic working mode (automatic and non-stop work mode)
• Compressed air pressure controller with filter.
• Fast cycles: Saved time of belt progress, adjustable by split second, when the hood is lifted in order to speed-up cycles.
• Easy access to chamber for cleaning and repairs.
• Quick change of conveyor belt.
• Quick access to electric boards.
• Stainless chassis and frame.
• Selector of the belt washing function in order to clean with pressurized water without dismantling. Reachable greasing points.
• Spare parts list.
• CE Standards certificate about machine uses and safety.
